6 Ways to Transform Legacy Data Storage Infrastructure

Learn how to maximize your existing data storage investments.

Jim O'Reilly

February 12, 2018

7 Slides

So you have a bunch of EMC RAID arrays and a couple of Dell iSCSI SAN boxes, topped with a NetApp filer or two. What do you say to the CEO who reads my articles and knows enough to ask about solid-state drives, all-flash appliances, hyperconverged infrastructure, and all the other new innovations in storage? “Er, er, we should start over” doesn’t go over too well! Thankfully, there are some clever -- and generally inexpensive -- ways to answer the question, keep your job, and even get a pat on the back.

SSD and flash are game-changers, so they need to be incorporated into your storage infrastructure. SSDs are better than enterprise-class hard drives from a cost perspective because they will speed up your workload and reduce the number of storage appliances and servers needed. It’s even better if your servers support NVMe, since the interface is becoming ubiquitous and will replace both SAS and (a bit later) SATA, simply because it’s much faster and lower overhead.

As far as RAID arrays, we have to face up to the harsh reality that RAID controllers can only keep up with a few SSDs. The answer is either an all-flash array and keeping the RAID arrays for cool or cold secondary storage usage, or a move to a new architecture based on either hyperconverged appliances or compact storage boxes tailored for SSDs.

All-flash arrays become a fast storage tier, today usually Tier 1 storage in a system. They are designed to bolt onto an existing SAN and require minimal change in configuration files to function. Typically, all-flash boxes have smaller capacities than the RAID arrays, since they have enough I/O cycles to do near-real-time compression coupled with the ability to down-tier (compress) data to the old RAID arrays.

With an all-flash array, which isn’t outrageously expensive, you can boast to the CEO about 10-fold boosts in I/O speed, much lower latency , and as a bonus a combination of flash and secondary storage that usually has 5X effective capacity due to compression. Just tell the CEO how many RAID arrays and drives you didn’t buy. That’s worth a hero badge!

The idea of a flash front-end works for desktops, too. Use a small flash drive for the OS (C-drive) and store colder data on those 3.5” HDDs. Your desktop will boot really quickly, especially with Windows 10 and program loads will be a snap.

Within servers, the challenge is to make the CPU, rather than the rest of the system, the bottleneck. Adding SSDs as primary drives makes sense, with HDDs in older arrays doing duty as bulk secondary storage, just as with all-flash solutions, This idea has fleshed out into the hyperconverged infrastructure (HCI) concept where the drives in each node are shared with other servers in lieu of dedicated storage boxes. While HCI is a major philosophical change, the effort to get there isn’t that huge.

For the savvy storage admin, RAID arrays and iSCSI storage can both be turned into powerful object storage systems. Both support a JBOD (just a bunch of drives) mode, and if the JBODs are attached across a set of server nodes running “free” Ceph or Scality Ring software, the result is a decent object-storage solution, especially if compression and global deduplication are supported.

Likely by now, you are using public clouds for backup. Consider “perpetual “storage using a snapshot tool or continuous backup software to reduce your RPO and RTO. Use multi-zone operations in the public cloud to converge DR onto the perpetual storage setup, as part of a cloud-based DR process. Going to the cloud for backup should save a lot of capital expense money.

On the software front, the world of IT is migrating to a services-centric software-defined storage (SDS), which allows scaling and chaining of data services via a virtualized microservice concept. Even older SANs and server drives can be pulled into the methodology, with software making all legacy boxes in a data center operate as a single pool of storage. This simplifies storage management and makes data center storage more flexible.

Encryption ought to be added to any networked storage or backup. If this prevents even one hacker from reading your files in the next five years, you’ll look good! If you are running into a space crunch and the budget is tight, separate out your cold data, apply one of the “Zip” programs and choose the encrypted file option. This saves a lot of space and gives you encryption!

Let’s take a closer look at what you can do to transform your existing storage infrastructure and extend its life.

(Image: Production Perig/Shutterstock)

About the Author(s)

Jim O'Reilly

President

Jim O'Reilly was Vice President of Engineering at Germane Systems, where he created ruggedized servers and storage for the US submarine fleet. He has also held senior management positions at SGI/Rackable and Verari; was CEO at startups Scalant and CDS; headed operations at PC Brand and Metalithic; and led major divisions of Memorex-Telex and NCR, where his team developed the first SCSI ASIC, now in the Smithsonian. Jim is currently a consultant focused on storage and cloud computing.
